BLUESTAR- 1TR 3STAR INVERTER- IB312TKU

Series Name : IB312TKU
Nominal Cooling Capacity (tonnage) : 1
Star Rating : 3 star
• High ISEER of 5.41
• 5-in-1 Convertible
• Turbo Cool
• Anti-Microbial Filter
• Smart Ready
• Nano BluProtect Technology
Rated) Voltage/Frequency/Phase : 230 V / 50Hz / Single
Cooling Capacity (Watt)(Min~Max) : 3450(1633?3735)
Cooling Capacity (BTU/hr) : 11771
Rated Cooling Capacity (50% Load) (Watt) : 1725
Cooling Rated Power Input (Watt) : 1100
Cooling Capacity (BTU/hr)(Min~Max) : 11771(5571?12743)
Cooling Power Input (50% Load) (Watt) : 418
ISEER : 3.9
Electricity Consumed In 1600 Hours. (Units/Year) : 684.94
Nominal Current (Cooling)(Amps) : 5.05
Air Flow Volume (Wet CFM) (High / Medium / Low) : 323/255/185/141
Noise Level Indoor (dB(a)) (High/ Medium/ Low) : 44.2/39.7/37.3 /33.6
Moisture Removal (Litres/Hour) : 1.31
Compressor Type : Inverter Rotary
Acoustic Jacket On Compressor : Yes
Refrigerant Quantity(Kg) : 0.43
Ambient Temp (Cooling) (degree C) : 52
Remote : LCD Remote with Display
Night Glow Function On Remote Buttons : Yes
Net IDU(Product) Dimension (mm) : 798 x 300 x 203
Input Power Supply : IDU
Net Weight IDU (kg) : 8.3
Net ODU Dimensions (Width X Depth X Height) (mm) : 740 x 442 x 250
Net Weight ODU (kg) : 19.5
Noise Level Outdoor (dB(a)) : 55
Gross IDU Weight (kg) : 10.2
Gross ODU Weight (kg) : 22
Suction Tube Size Outer Diameter Inch (mm) : 3/8\" (9.525mm)
Liquid Tube Size Outer Diameter Inch (mm) : 1/4\" (6.35mm)
Max Piping Capability Total (meter) : 15
Max Piping Capability Vertical (meter) : 10
Refrigerant Additional Charge Beyond 4M (g/m) : 15
Power Supply to ODU Source(Core/Gauge) : 4C * 1.0sqmm
Power Supply to IDU Source(Core/Gauge) : 3C * 1.0sqmm
Features Refrigerant : R32

Features Condenser Type : 100% Copper Air Conditioner Technology : Inverter
Features Additional Warranty Option : 1+4 Year Extended Warranty
