BLUESTAR - 1.5TR 3STAR - INVERTER - IC318MNU

Series Name : IC318MNU
Nominal Cooling Capacity (tonnage) : 1.5
Star Rating : 3 star
• Smart Ready
• PM2.5 Filter with Activated Carbon
• 5-in-1 Convertible
• AI Pro
• Turbo Coo
• DigiQ Penta Sensors
(Rated) Voltage/Frequency/Phase : 230 V / 50Hz / Single
Cooling Capacity (Watt)(Min~Max) : 5050 (1415 ~ 5472)
Cooling Capacity (BTU/hr) : 17230
Rated Cooling Capacity (50% Load) (Watt) : 2525
Cooling Rated Power Input (Watt) : 1590
Cooling Capacity (BTU/hr)(Min~Max) : 17230 (4828 ~ 18670)
Cooling Power Input (50% Load) (Watt) : 610
ISEER : 3.93
Electricity Consumed In 1600 Hours. (Units/Year) : 995.24
Nominal Current (Cooling)(Amps) : 7.2
Air Flow Volume (Wet CFM) (High / Medium / Low) : 514/450/415
Noise Level Indoor (dB(a)) (High/ Medium/ Low) : 48.5/45.5/39.1
Moisture Removal (Liters/Hour) : 1.2
Compressor Type : Inverter Rotary
Acoustic Jacket On Compressor : Yes
Refrigerant Quantity(Kg) : 0.62
Ambient Temp (Cooling) (degree C) : 52
Remote : LCD Remote with Display
Night Glow Function On Remote Buttons : Yes
Net IDU(Product) Dimension (mm) : 960 x 215 x 320
Input Power Supply : IDU
Net Weight IDU (kg) : 12
Net ODU Dimensions (Width X Depth X Height) (mm) : 858 x 327 x 536
Net Weight ODU (kg) : 25
Noise Level Outdoor (dB(a)) : 60
Gross IDU Weight (kg) : 13.3
Gross ODU Weight (kg) : 28.7
Suction Tube Size Outer Diameter Inch (mm) : 1/2\" (12.7mm)
Liquid Tube Size Outer Diameter Inch (mm) : 1/4\" (6.35mm)
Max Piping Capability Total (meter) : 15
Max Piping Capability Vertical (meter) : 10
Refrigerant Additional Charge Beyond 4M (g/m) : 15
Power Supply to ODU Source(Core/Gauge) : 4C * 1.5sqmm
Power Supply to IDU Source(Core/Gauge) : 3C * 1.5sqmm
Features Refrigerant : R32
Features Condenser Type : 100% Copper
Air Conditioner Technology : Inverter
Features Warranty : 10 Year Warranty on Inverter Compressor
Features Additional Warranty Option : 1+4 Year Extended Warranty
